Half Cells 645W 650W 655W 660W 665W 670W Solar PV Panels High Efficiency Monocrystalline PERC MBB Photovoltaic Solar Panel Module Based on 210mm Solar Cells
Brand Name :
SAIL SOLARPower Range :
645~670WDimensions of Module :
2384×1303×35 mmWeight :
33.6kgGlass :
Single glass, 3.2mm coated tempered glassFrame :
Anodized aluminum alloy frameJunction Box :
IP68, three diodesCable :
4mm2, 300mm in length, length can be customizedMax. Efficiency :
21.57%Wind/Snow Load :
5400Pa/2400PaNumber of Cells :
132ellsBacksheet :
WhitePacking :
MC4210mm PERC Half Cult 132Cells MBB Mono 645Watt ~670Watt Solar Panel
PERC cells have obvious performance and cost advantages. They are well compatible with existing cell and module production lines, and at the same time achieve an efficiency increase of about 1%, becoming the first high-efficiency cell technology that has achieved a breakthrough in large-scale commercialization.
The peak product in the industry, with a rated power of up to 700W, super large size and super high efficiency, is the best choice for super power station installation.
Future mainstream solar panels, single face encapsulated, stable performance to guarantee power plant’ s generation.
Better energy yield with excellent low irradiance performance and temperature coefficient.
12-year product and workmanship warranty, 30-year linear power output warranty.
First year power degradation <2%
glass lamination ensures 30 years product lifetime, with annual power degradation < 0.55%
| Module ID | SAS645M-132H | SAS650M-132H | SAS655M-132H | SAS660M-132H | SAS665M-132H | SAS670M-132H |
| Maximum Power (Pmax/W) | 645 | 650 | 655 | 660 | 665 | 670 |
| Maximum Power Voltage (Vmp/V) | 37.20 | 37.40 | 37.60 | 37.80 | 38.00 | 38.20 |
| Maximum Power Current (Imp/A) | 17.34 | 17.38 | 17.43 | 17.47 | 17.50 | 17.54 |
| Open Circuit Voltage (Voc/V) | 45.00 | 45.20 | 45.40 | 45.60 | 45.80 | 46.00 |
| Short Circuit Current (Isc/A) | 18.37 | 18.42 | 18.47 | 18.52 | 18.57 | 18.62 |
| Module Efficiency (%) | 20.76 | 20.92 | 21.09 | 21.25 | 21.41 | 21.57 |
| Power Output Tolerance (W) |
0~+5W | |||||
| Temperature Coefficient of Isc |
+0.050%/°C | |||||
| Temperature Coefficient of Voc |
-0.290%/°C | |||||
| Temperature Coefficient of Pmax | -0.340%/°C | |||||
STC (Standard Testing Conditions): Irradiance 1000W/m2, Cell Temperature 25°C, Spectra at AM1.5
Test uncertainty for Pmax: ±3%
Certification
SAIL SOALR' s pv panel module have been certified by professional third-party testing bodies around the world, and the testing conditions are complex and diverse, from ordinary installation conditions to various extreme weather conditions, natural environments etc. We do our best to provide customers with quality products, for the customer's investment and income to provide protection.
