Lead Carbon batteries use functional activated carbon and graphene as carbon materials, which are added to the negative plate of the battery to make lead carbon batteries have the advantages of both lead-acid batteries and super capacitors.
Brand Name :
SAIL SOLARProduct Model :
2V, 12VCapacity Range :
2V400Ah-2000Ah, 12V100Ah-200AhTerminal Type :
M6/M8Number of Cycles :
3000+timesEfficiency :
≥98%Design Life :
20 years at 25℃Operation Temperature :
-40℃~60℃Self Discharge Rate :
≤3% per monthApplication :
UPS/EPS systems Solar energy system/Wind Energy System Renewable Energy Systems Energy storage projectsColor&OEM :
White or Black is optional, can be customized. Support OEMCertificates :
CE/ IEC60829-21/22-2004/ IEC61427-2005/ISO9001/ISO14001/OHSAS18001
Lead Carbon Battery Technology
Lead-carbon battery is the combination of a lead-carbon dual function negative pole plate which makes of both dual electric layer capacitance carbon material (C) and lead (Pb) to achieve the capacitance & battery feature, then the lead-carbon batteries assembled by lead-carbon negative pole plate and positive pole plate.
The main application of Lead-carbon battery is Energy Storage. Lead-carbon battery has the fast recharge and big current charge/discharge function to offer stable performance. Adding carbon is to eliminate the polarization of the negative electrode. Under the same process conditions, the charging voltage of lead acid battery without carbon can reach to 16V ~ 17V, and the lead-carbon battery voltage is 15.5V ~ 16.5V only.
Lead Carbon Battery Characteristic
-It is recommended to store at an ambient temperature ranging from -20°C to +50°C.
-When the battery is stored, the battery must be fully charged. As part of the capacity will be lost due to self-discharge during transportation or storage, please recharge before use.
-For long-term storage, please recharge regularly (it is recommended to recharge once every six months).
-Please store in a dry and well-ventilated place with low temperature
-Terminal: M6/M8 Copper Insert
-Cycle Use Voltage: 2.30~2.33Vpc(25 °C)
-Temperature Compensation : -4mV/°C/Cell
-Operating Temperature Range: 15 °C~30°C
-Max. Operating Temperature Range:-20~60°C
Lead Carbon Battery Application
-Home energy storage system
-Smart power grid and micro-grid system
-Distributed energy storage system
-Solar and wind energy storage system
-Solar power generation grid or off-grid energy storage system
-Generation and battery hybrid energy storage system
Certification
